Concertina type razor barbed wire coil

Concertina type razor barbed wire coil

• Category:Barbed Razor Wire
• Material:Galvanized steel sheet and wire, also stainless steel sheet and wire
• Properties:security mesh
• Application: widely used by many countries in military fields, prisons, governments buildings and other national facilities.

tags:
concertina razor barbed wire,razor barbed wire,

Inquiry now

or

Send email

We highly appreciate your feedback. TEL:0086-10-68283337 TEL: 0086-10-68283337 E-mail: sales@kingdamesh.com

• Mesh Description
• Mesh Specification
• Relevant Picture
• Recommend Products

Concertina type razor barbed wire coil
1.Wire dia2.5+-0.1mm
2.Thickness0.5+-0.05mm
3.Barb Length:18+-1,22+-1mm
4.Barb width :15+-1mm
Razor barbed wire
Materials: Galvanized steel sheet and wire, also stainless steel sheet and wire out diameter: 450mm, 500mm, 760mm, 900mm or so.
Features: secure fencing, easy installation, age resistance and other properties.
Concertina razor barbed wire
Usage:
1. As its corrosion resistance, high protection, is widely used by many countries in military fields, prisons, governments buildings and other national facilities.
2. They are usually used together with the fence products, such as the welded fence, chain link fence, etc.

Razor Blade Specification:

Reference Number	Thickness	Wire Dia.	Barb Length	Barb Width	Barb spacing
BTO-10	0.5±0.05	2.5±0.1	10±1	13±1	26±1
BTO-12	0.5±0.05	2.5±0.1	12±1	15±1	26±1
BTO-18	0.5±0.05	2.5±0.1	18±1	15±1	33±1
BTO-22	0.5±0.05	2.5±0.1	22±1	15±1	34±1
BTO-28	0.5±0.05	2.5	28	15	45±1
BTO-30	0.5±0.05	2.5	30	18	45±1
CBT-60	0.6±0.05	2.5±0.1	60±2	32±1	100±2
CBT-65	0.6±0.05	2.5±0.1	65±2	21±1	100±2

Barbed tape wire Specification:

Outside Diameter	No. of Loops	Standard Length per Coil	Type	Notes
450mm	33	7-8M	CBT-60.65	Single coil
500mm	56	12-13M	CBT-60.65	Single coil
700mm	56	13-14M	CBT-60.65	Single coil
960mm	56	14-15M	CBT-60.65	Single coil
450mm	56	8-9M (3 CLIPS)	BTO-10.12.18.22.28.30	Cross type
500mm	56	9-10M (3 CLIPS)	BTO-10.12.18.22.28.30	Cross type
600mm	56	10-11M (3 CLIPS)	BTO-10.12.18.22.28.30	Cross type
600mm	56	8-10M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
700mm	56	10-12M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
800mm	56	11-13M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
900mm	56	12-14M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
960mm	56	13-15M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type
980mm	56	14-16M (5 CLIPS)	BTO-10.12.18.22.28.30	Cross type

•
