Elliptical hole perforated sheet

Category:Perforated Metal Mesh
Material:low carbon steel ,stainless steel, aluminum
Properties:High strength, toughness, resistance to bending
Application:widely used in filter element, making of medicine

tags:
Elliptical hole perforated sheet, perforated sheet,

Inquiry now

Send email

We highly appreciate your feedback. TEL: 0086-10-68220585 E-mail: sales@kingdamesh.com

Mesh Description
Mesh Specification
Relevant Picture
Recommend Products

Elliptical hole perforated sheet
The specifications of Elliptical hole perforated sheet
1. The materials: low carbon steel ,stainless steel, aluminum, alloy steel, galvanized steel
2. Wire diameters and Elliptical hole perforated sheet size can be according to your request
3. Surface treatment: electrostatic powder coating.
4. Sheet thickness: 0.5mm to 30mm etc.
5. Packing: according to customers requirement
The features of Elliptical hole perforated sheet
High strength, toughness, resistance to bending, anti-aging, anti-flame resistance, high temperature, acid, strong ability to withstand bending excellent performance
The applications of Elliptical hole perforated sheet
1. Applications: widely used in filter element, making of medicine, filtering, breeding, battery, mechanical protecting, making of handicrafts, high-grade sound box, decoration, the seating for children, making of small basket and shelves.
2. USES: Power plants, coal mines, coking plants, coal washing plant, and other businesses to save coal field; Ports, terminals and markets a variety of coal storage yard; Iron and steel, building materials, cement companies such as a variety of open-air yard; Coal storage and station of Railway and highway transportation; Sites, road dust.
If you are interested in our products, pls feel free to contact us. TEL: 0086-10-68283337, Email: service.wzjd@hotmail.com

Reference specification of Elliptical hole perforated sheet

Sheet thickness	Opening in width(mm)	Opening in length (mm)	Stem (mm)	Roll width (mm)	Roll length (mm)	Weight (Kg/m2)
0.5	2.5	4.5	0.5	0.5	1	1.8
0.5	10	25	0.5	0.6	2	0.73
0.6	10	25	1	0.6	2	1
0.8	10	25	1	0.6	2	1.25
1	15	25	1.1	0.6	2	1.77
1	10	40	1.5	24	4	1.85
1.2	15	25	1.1	24	4	2.21
1.2	15	40	1.5	24	4	2.3
1.5	15	40	1.5	1.8	4	2.77
1.5	23	60	2.6	2	3.6	2.77
2	18	50	2.1	2	4	3.69
2	22	60	2.6	2	4	3.69
4	80	180	4	2	10	3
3	40	80	3.8	2	4	5
4	40	100	4	2	2	11.15
4.5	50	100	5	2	2.7	11.15
5	50	100	6	1.4	2.6	12.39
6	50	100	8	2	2.5	17.35
8	50	100	8	2	2.1	28.26
