Iron Plate Perforated Metal
Iron Plate Perforated Metal
- Category:Perforated Metal Mesh
- Material:Steel, Carbon Steel, Aluminum, Stainless Steel
- Properties:perforated mesh
- Application:Separation, filtration, dehydration, Juicers, drying, screening.
tags:
Iron Plate Perforated Metal,iron Perforated Metal,
or
We highly appreciate your feedback. TEL: 0086-10-68220585 E-mail: sales@kingdamesh.com
- Mesh Description
- Mesh Specification
- Relevant Picture
- Recommend Products
Iron Plate perforated Metal
1. Material of Iron Perforated Metal: Steel, Carbon Steel, Aluminum, Stainless Steel, Galvanized Steel, Aluminum coated Steel.
2. Hole Diameter: 0.3-500mm
3. Plate Thickness: 0.2-30mm
4. Thickness or Gauge
Thickness of the metal sheets does not change during the perforation. Normally thickness is expressed in gauge, please see the picture. However, to avoid possible misunderstanding, we would suggest expressing them in inches or millimeters.
5. Width and Length Iron Perforated Metal:
The most common width and length are as follows:
1000mmX2000mm
1220mmX2400mm
1250mmX2500mm
1250mmX6000mm
1500mmX3000mm
1500mmX6000mm
However, we also manufacture other sheet sizes according to clients' requests.
6. Margins of Iron Perforated Metal:
Margins are the blank (un-perforated) area along the edges of the sheet. Normally the margin on the length are 20mm minimum, and margin along the width can be 0 minimum, or at clients' requests.
7. Hole Arrangement of Iron Perforated Metal:
Round holes are normally arranged in 3 types. Other hole patterns and hole arrangements can be custom made.
Mainly used in: Separation, filtration, dehydration, Juicers, drying, screening, decentralized, grinding, grinding machinery of filters and other purposes.
