Metal perforated panels

Category:Perforated Metal Mesh
Material:low carbon steel sheet, galvanized steel sheet, aluminium sheet,etc
Properties:Perforated mesh
Application:sound suppression, microwaves, purification

tags:
Metal panels,perforated panels,

Inquiry now

Send email

We highly appreciate your feedback. TEL: 0086-10-68220585 E-mail: sales@kingdamesh.com

Mesh Description
Mesh Specification
Relevant Picture
Recommend Products

Metal perforated panels
1. Material: Wuzhou Kingda hold expertise in manufacturing and supplying wide range of metal perforated panels that are precisely manufactured using optimum quality aluminum, copper, titanium, brass, magnesium, bronze, and galvanized steel. Besides, we can work with you on any custom fabricated metal application, such as perforated tubes, perforated belts, perforated infill panels, and perforated columns.
2. Metal perforated panels features:
Dimensionally accurate
High tensile strength
Feasible rates
3. Application of the Metal perforated panels:
Metal perforated panels offer wide application in sound suppression, microwaves, purification and filtration of air and in gases and water. Additionally clients can also use these in perforated panels and heavy gauge perforations and in radiation containment.

If you are interested, please feel free to contact the following: TEL: 0086-10-68285557 E-mail: service.wzjd@hotmail.com

Reference specifications of Metal perforated panels:

Plate Material	Thickness of Metal (mm)	Hole Dia. (mm)	Pitch (mm)	Sheet Width (m)	Sheet Length (m)	Porosity (%)	Weight (kg/m2)
Rolling plate	0.2	6	2	1	20	44	0.88
	0.35	5	4	1	20	24	2
	0.45	6	3	1	20	35	2.5
	0.8	3	3	1	20	19.6	3
Flat plate	0.5	1	1	1	2	19.6	3.14
	0.55	1.1	2.2	1	2	22.67	3.411
	0.55	1.5	2.8	1	2	26.03	3.268
	0.8	1.5	1.5	1	2	19.6	5
	0.8	2.0	3.4	1	2	30.78	4.465
	1.5	2	2	1	2	19.6	9.4
	1.5	5.0	8.0	1	2	35.39	7.843
	3	5	16	1	2	19.6	18.8
Stainless steel plate	0.5	1	1	1	2	19.6	3.14
	0.8	1.5	1.5	1	2	19.6	5
	1	2	2	1	2	19.6	6.28
	2	5	16	1	2	19.6	6.28
Aluminum plate	0.5	1	1	1	2	19.6	1.08
	0.8	3	3	1	2	19.6	1.72
	1.6	2	2	1	2	19.6	3.24
	3	4	16	1	2	19.6	4.23
