Perforated metal screen

Category:Perforated Metal Mesh
Material:plate of Iron, zinc-coated, aluminum
Properties:perforated mesh
Application:widely applied in petroleum chemical, mine, power plant, building engineering.

tags:
perforated metal,perforated screen,

Inquiry now

Send email

We highly appreciate your feedback. TEL: 0086-10-68220585 E-mail: sales@kingdamesh.com

Mesh Description
Mesh Specification
Relevant Picture
Recommend Products

Perforated metal screen
SpecificationsThickness0.03mm-15mm
Material: plate of Iron, zinc-coated, aluminum
Perforated metal screen
Material: plate of Iron, zinc-coated, aluminum, stainless steel, brass/copper/phosphor copper or PVC. produced to punching mesh, perforated metal, perforated wire mesh, perforated screen, Punched mesh, punch hole mesh.
Perforated metal mesh SpecificationsThickness0.03mm-15mm
The use of stainless steel perforated sheet in Water Treatment Works is becoming more common. Where ceramic tiles need to be entirely replaced, a cost effective option is to adopt the use of perforated stainless steel plate.
Perforated metal screen
Applications: widely applied in petroleum chemical, mine, power plant, building engineering, protection, ventilation, decoration, furniture, agricultural mechanism, mine mechanism, space, etc.

Plate Material	Thickness of Metal (mm)	Hole Dia. (mm)	Pitch (mm)	Sheet Width (m)	Sheet Length (m)	Porosity (%)	Weight (kg/m2)
Rolling plate	0.2	6	2	1	20	44	0.88
	0.35	5	4	1	20	24	2
	0.45	6	3	1	20	35	2.5
	0.8	3	3	1	20	19.6	3
Flat plate	0.5	1	1	1	2	19.6	3.14
	0.55	1.1	2.2	1	2	22.67	3.411
	0.55	1.5	2.8	1	2	26.03	3.268
	0.8	1.5	1.5	1	2	19.6	5
	0.8	2.0	3.4	1	2	30.78	4.465
	1.5	2	2	1	2	19.6	9.4
	1.5	5.0	8.0	1	2	35.39	7.843
	3	5	16	1	2	19.6	18.8
Stainless steel plate	0.5	1	1	1	2	19.6	3.14
	0.8	1.5	1.5	1	2	19.6	5
	1	2	2	1	2	19.6	6.28
	2	5	16	1	2	19.6	6.28
Aluminum plate	0.5	1	1	1	2	19.6	1.08
	0.8	3	3	1	2	19.6	1.72
	1.6	2	2	1	2	19.6	3.24
	3	4	16	1	2	19.6	4.23
