Perforated metal wire mesh
1. Material: Perforated metal wire mesh is made of low-carbon steel plate, stainless steel plate, copper plate, nickel board.
2. Perforated metal wire mesh features: sturdy and durable, elegant appearance, high precision, small deviation and good quality.
3. Application of Perforated metal wire mesh:
We provide high performance perforated metal wire mesh that are extensively used in decorations, oil field drilling, engineering, mine screening, constructions and various other applications. Our perforated metal is manufactured from the optimum quality raw materials to add durability and efficiency. Robust construction, our Perforated metal is known for anti abrasive nature and low maintenance cost.

Reference specifications of Perforated metal mesh:
1) Production technology: punch forming
2) Material: stainless steel, low carbon steel, galvanized steel
3) Plate thickness: 5-10mm
4) Aperture: 0.4-100mm
5) Hole pattern: round, square, triangle, diamond, oval, hexagon and so on

Plate Material	Thickness of Metal (mm)	Hole Dia. (mm)	Pitch (mm)	Sheet Width (m)	Sheet Length (m)	Porosity (%)	Weight (kg/m2)
Rolling plate	0.2	6	2	1	20	44	0.88
	0.35	5	4	1	20	24	2
	0.45	6	3	1	20	35	2.5
	0.8	3	3	1	20	19.6	3
Flat plate	0.5	1	1	1	2	19.6	3.14
	0.55	1.1	2.2	1	2	22.67	3.411
	0.55	1.5	2.8	1	2	26.03	3.268
	0.8	1.5	1.5	1	2	19.6	5
	0.8	2.0	3.4	1	2	30.78	4.465
	1.5	2	2	1	2	19.6	9.4
	1.5	5.0	8.0	1	2	35.39	7.843
	3	5	16	1	2	19.6	18.8
Stainless steel plate	0.5	1	1	1	2	19.6	3.14
	0.8	1.5	1.5	1	2	19.6	5
	1	2	2	1	2	19.6	6.28
	2	5	16	1	2	19.6	6.28
Aluminum plate	0.5	1	1	1	2	19.6	1.08
	0.8	3	3	1	2	19.6	1.72
	1.6	2	2	1	2	19.6	3.24
	3	4	16	1	2	19.6	4.23
