Five-heddle weave stainless steel wire mesh

Five-heddle weave stainless steel wire mesh

• Category:Stainless Steel Wire Mesh
• Material:Low carbon steel wire and so on
• Properties:Woven Wire Mesh
• Application:filtration industry and so on

tags:
Five-heddle weave stainless steel wire mesh,Five-Heddle Weave Wire Cloth, stainless steel wire mesh,weave stainless steel mesh,

Inquiry now

or

Send email

We highly appreciate your feedback. TEL: 0086-10-68220585 E-mail: sales@kingdamesh.com

• Mesh Description
• Mesh Specification
• Relevant Picture
• Recommend Products

Five-heddle weave stainless steel wire mesh
1. Materials of Five-heddle weave stainless steel wire mesh: High quality stainless steel wire of 304,304L, 316, 316L. A filter mesh characterized by a 5-heddle-atlas pattern. This special weaving style makes it possible to produce open meshes with high flow rates combined with great mechanical stability. At the same time, it creates a smooth surface for easy removal of filter cake and trouble-free cleaning of the filter media.
2. Product name: five-heddle weave is divided as single layer mesh, double layer mesh , two and a half layer mesh, three layer mesh etc.
3. Typical Use of Five-heddle weave stainless steel wire mesh:
Five-Heddle Weave Wire Cloth is popular in applications including pressure and vacuum filters as well as filter candles. Industrial woven wire cloth and woven wire mesh are used as filtration of petroleum in chemical industries, in the form of filter ribbons or filter elements. It has proven especially applicable in drum filter equipment and in disc filters where the buildup of the filter cake, the removal and the cleaning are performed in continuous cycles. These meshes are used in waste water treatment, process water filtration and in the mining industry. Five-Heddle Weave Wire Mesh offers high flow rates and it is suitable for high mechanical loads, featuring a lightly structured mesh surface.

Specification of Five-heddle weave stainless steel wire mesh:

Standard No		Wire diameter		Micro retention		Weight in kg	Thickness In mm	Flow ratings
Warp Per 25.4mm	Weft Per 25.4mm	Warp In mm	Weft In mm	abs. μm	nom. μm			Water l/cm2h*200mbar	Air Nm3/h*20cm 2/2mbar
132	85	0.140	0.200	0.09-0.11	0.052	1.47	0.44	402	17.30
107	132	0.160	0.140	0.055-0.065	0.055	1.30	0.44	424	19.80
107	125	0.160	0.140	0.065-0.08	0.070	1.27	0.45	480	23.90
107	59	0.160	0.160	0.16-0.18	0.077	1.09	0.45	995	46.00
80	60	0.200	0.200	0.20-0.22	0.127	1.40	0.55	1056	39.80
77	40	0.240	0.240	0.38-0.40	0.095	1.65	0.68	1022	42.90
65	36	0.300	0.300	0.26-0.29	0.100	2.27	0.84	996	48.50
55	36	0.300	0.300	0.25-0.28	0.175	2.05	0.84	900	40.20
48	45	0.400	0.400	0.17-0.21	0.130	3.79	1.11	1080	49.90
48	45	0.290	0.290	0.24-0.26	0.230	2.00	0.83	1135	49.50
48	25	0.300	0.300	0.46-0.50	0.250	2.73	0.82	1164	54.00
30	18	0.500	0.500	0.60-0.65	0.370	3.00	1.48	1200	63.00
28	17	0.470	0.470	0.75-0.80	0.460	2.53	1.41	1400	64.20
24	20	0.600	0.600	0.65-0.75	0.490	3.96	1.70	1254	57.10
15	13	0.900	0.900	1.15-1.20	0.850	5.67	2.60	1284	60.30

We can produce according to the customer’s requirements.

•
