Mesh stainless steel,Mesh stainless steel supplier-Wuzhou Kingda Wire Cloth Co. Ltd

Mesh stainless steel

Category:Stainless Steel Wire Mesh
Material:Stainless steel wire
Properties:Woven Wire Mesh
Application:uses in processing of oils, chemicals, food, pharmaceuticals

tags:
Mesh stainless steel,

Inquiry now

Send email

We highly appreciate your feedback. TEL: 0086-10-68220585 E-mail: sales@kingdamesh.com

Mesh Description
Mesh Specification
Relevant Picture
Recommend Products

Mesh stainless steel
1. Mesh stainless steel Materials: SUS302, 304, 316, 304L, 316L.
2. Typical Weaving Patterns of Mesh stainless steel: Plain weave, twill weave, Plain Dutch weave, Twilled Dutch weave.
3. Mesh stainless steel features:
Mesh stainless steel has the features of acid resisting, alkali resisting, and heat resisting. It also has a long using time.
4. Application of the Mesh stainless steel:
With its excellent resistance against acid, alkali, heat and corrosion, find extensive uses in processing of oils, chemicals, food, pharmaceuticals, Mesh stainless steel can also sorting and screening of solid, liquid and gas in mine, metallurgy, airspace, machine making, etc.

Reference specifications of the Mesh stainless steel:

Mesh	Wire Diameter		Aperture		Open Area	Weight (LB)/100 Square Feet
Mesh	inch	mm	Inch	mm	Open Area	Weight (LB)/100 Square Feet
1x1	. 080	2.03	. 920	23.37	84.6	41.1
2X2	. 063	1.60	. 437	11.10	76.4	51.2
3X3	. 054	1.37	. 279	7.09	70.1	56.7
4X4	. 063	1.60	. 187	4.75	56.0	104.8
4X4	. 047	1.19	. 203	5.16	65.9	57.6
5X5	. 041	1.04	. 159	4.04	63.2	54.9
6X6	. 035	. 89	. 132	3.35	62.7	48.1
8X8	. 028	. 71	. 097	2.46	60.2	41.1
10X10	. 025	. 64	. 075	1.91	56.3	41.2
10X10	. 020	. 51	. 080	2.03	64.0	26.1
12X12	. 023	. 584	. 060	1.52	51.8	42.2
12X12	. 020	. 508	. 063	1.60	57.2	31.6
14X14	. 023	. 584	. 048	1.22	45.2	49.8
14X14	. 020	. 508	. 051	1.30	51.0	37.2
16X16	. 018	. 457	. 0445	1.13	50.7	34.5
18X18	. 017	. 432	. 0386	. 98	48.3	34.8
20X20	. 020	. 508	. 0300	. 76	36.0	55.2
20X20	. 016	. 406	. 0340	. 86	46.2	34.4
24X24	. 014	. 356	. 0277	. 70	44.2	31.8
30X30	. 013	. 330	. 0203	. 52	37.1	34.8
30X30	. 012	. 305	. 0213	. 54	40.8	29.4
30X30	. 009	. 229	. 0243	. 62	53.1	16.1
35X35	. 011	. 279	. 0176	. 45	37.9	29.0
40X40	. 010	. 254	. 0150	. 38	36.0	27.6
50X50	. 009	. 229	. 0110	. 28	30.3	28.4
50X50	. 008	. 203	. 0120	. 31	36.0	22.1
60X60	. 0075	. 191	. 0092	. 23	30.5	23.7
60X60	. 007	. 178	. 0097	. 25	33.9	20.4
70X70	. 0065	. 165	. 0078	. 20	29.8	20.8
80X80	. 0065	. 165	. 0060	. 15	23.0	23.2
80X80	. 0055	. 140	. 0070	. 18	31.4	16.9
90X90	. 005	. 127	. 0061	. 16	30.1	15.8
100X100	. 0045	. 114	. 0055	. 14	30.3	14.2
100X100	. 004	. 102	. 0060	. 15	36.0	11.0
100X100	. 0035	. 089	. 0065	. 17	42.3	8.3
110X110	. 0040	. 1016	. 0051	. 1295	30.7	12.4
120X120	. 0037	. 0940	. 0064	. 1168	30.7	11.6
150X150	. 0026	. 0660	. 0041	. 1041	37.4	7.1
160X160	. 0025	. 0635	. 0038	. 0965	36.4	5.94
180X180	. 0023	. 0584	. 0033	. 0838	34.7	6.7
200X200	. 0021	. 0533	. 0029	. 0737	33.6	6.2
250X250	. 0016	. 0406	. 0024	. 0610	36.0	4.4
270X270	. 0016	. 0406	. 0021	. 0533	32.2	4.7
300X300	. 0051	. 0381	. 0018	. 0457	29.7	3.04
325X325	. 0014	. 0356	. 0017	. 0432	30.0	4.40
400X400	. 0010	. 0254	. 0015	. 370	36.0	3.3
500X500	. 0010	. 0254	. 0010	. 0254	25.0	3.8
635X635	. 0008	. 0203	. 0008	. 0203	25.0	2.63
