stainless steel woven wire

Category:Stainless Steel Wire Mesh
Material:stainless steel ss302, 304, 304L, 316, 316L.
Properties:stainless steel wire mesh
Application:used in processing of oils, chemicals, food, pharmaceuticals.

tags:
stainless steel woven wire,stainless steel wire mesh,

Inquiry now

Send email

We highly appreciate your feedback. TEL: 0086-10-68220585 E-mail: sales@kingdamesh.com

Mesh Description
Mesh Specification
Relevant Picture
Recommend Products

stainless steel woven wire
Major material: stainless steel ss302, 304, 304L, 316, 316L.
Weave: plain weave, plain Dutch weave, twilled weave or herring bone weave
features: excellent resistance against acid, alkali, heat and corrosion
Mesh: always 2mesh-400mesh. We also can make the mesh count as customer’s requirement.

stainless steel woven mesh
Used: uses in processing of oils, chemicals, food, pharmaceuticals, also sorting and screening of solid, liquid and gas in mine, metallurgy, airspace, machine making, etc.

Specification of stainless steel wire mesh
mesh/inch	wire diameter( mm )	aperture( mm )	mesh/inch	wire diameter( mm )	aperture( mm )
2mesh	1.80	10.90	60mesh	0.15	0.273
3mesh	1.60	6.866	70mesh	0.14	0.223
4mesh	1.20	5.15	80mesh	0.12	0.198
5mesh	0.91	4.17	90mesh	0.11	0.172
6mesh	0.80	3.433	100mesh	0.10	0.154
8mesh	0.60	2.575	120mesh	0.08	0.132
10mesh	0.55	1.990	140mesh	0.07	0.111
12mesh	0.50	1.616	150mesh	0.065	0.104
14mesh	0.45	1.362	160mesh	0.053	0.094
16mesh	0.40	1.188	180mesh	0.065	0.088
18mesh	0.35	1.060	200mesh	0.053	0.074
20mesh	0.30	0.970	250mesh	0.04	0.061
26mesh	0.28	0.696	300mesh	0.035	0.049
30mesh	0.25	0.596	325mesh	0.03	0.048
40mesh	0.21	0.425	350mesh	0.03	0.042
50mesh	0.19	0.318	400mesh	0.25	0.0385
Electric Welding Net: 0.6m-1.5m
