Steel mesh screen

Category:Crimped Wire Mesh
Material:stainless steel wire, galvanized wire, steel wire, iron wire, brass wire
Properties:a strong and durable structure
Application: filters in mine, coal factory, construction and other industries

tags:
steel mesh screen,quarry screen mesh,

Inquiry now

Send email

We highly appreciate your feedback. TEL: 0086-10-68220585 E-mail: sales@kingdamesh.com

Mesh Description
Mesh Specification
Relevant Picture
Recommend Products

Steel mesh screen

The materials of steel mesh screen are stainless steel wire, galvanized wire, steel wire, iron wire, brass wire and so on.

The specifications of the steel mesh screen:

1. Wire diameter: 0.25-5mm

2. Aperture: 0.3-60mm

3. Width: 0.5-2.0m or as required

4. Length: 10-50m or as required

5. Packing: waterproof paper in coils and woven bag to prevent the moisture, then in pallet or wooden case to reduce the pressure when loading or as customers' requirements

6. Crimp methods of mine sieving crimped wire mesh

<1> Double Crimp

<2> Intermediate Crimp

<3> Lock Crimp

<4> Flat top Crimp

<5> Lock slot Crimp

The features of the steel mesh screen:

The steel mesh screen is woven with pre-crimped wire, so it has a strong and durable structure.

The applications of the steel mesh screen:

The steel mesh screen is applied as filters in mine, coal factory, construction and other industries. And some galvanized steel mesh screens are for roasting of flour food and meat.

If you are interested in our products, pls feel free to contact us. TEL: 0086-10-68283337, Email: service.wzjd@hotmail.com

Reference specification of the steel mesh screen

Mesh/Inch	Wire Diameter		Aperture		Open Area	Weight(LB) /100 Square Foot
Mesh/Inch	Inch	MM	Inch	MM	Open Area	Weight(LB) /100 Square Foot
1x1	0.08	2.03	0.92	23.37	84.6	41.1
2X2	0.063	1.6	0.437	11.1	76.4	51.2
3X3	0.054	1.37	0.279	7.09	70.1	56.7
4X4	0.063	1.6	0.187	4.75	56	104.8
24X24	0.014	0.356	0.0277	0.7	44.2	31.8
30X30	0.013	0.33	0.0203	0.52	37.1	34.8
35X35	0.011	0.279	0.0176	0.45	37.9	29
40X40	0.01	0.254	0.015	0.38	36	27.6
50X50	0.009	0.229	0.011	0.28	30.3	28.4
60X60	0.007	0.178	0.0097	0.25	33.9	20.4
70X70	0.0065	0.165	0.0078	0.2	29.8	20.8
80X80	0.0055	0.14	0.007	0.18	31.4	16.9
180X180	0.0023	0.0584	0.0033	0.0838	34.7	6.7
200X200	0.0021	0.0533	0.0029	0.0737	33.6	6.2
250X250	0.0016	0.0406	0.0024	0.061	36	4.4
270X270	0.0016	0.0406	0.0021	0.0533	32.2	4.7
300X300	0.0051	0.0381	0.0018	0.0457	29.7	3.04
325X325	0.0014	0.0356	0.0017	0.0432	30	4.4
400X400	0.001	0.0254	0.0015	0.37	36	3.3
500X500	0.001	0.0254	0.001	0.0254	25	3.8
635X635	0.0008	0.0203	0.0008	0.0203	25	2.63
