Perforated sheet

Category:Perforated Metal Mesh
Material:stainless steel plate,iron plate,copper plate,aluminum plate
Properties:winding-resisting,Aging-resisting,corrosion-resisting
Application:Widely applies in the chemical machinery, the drugs manufacture equipment

tags:
Perforated sheet,Perforated metal sheet,

Inquiry now

Send email

We highly appreciate your feedback. TEL: 0086-10-68220585 E-mail: sales@kingdamesh.com

Mesh Description
Mesh Specification
Relevant Picture
Recommend Products

Perforated sheet
The specification of Perforated sheet
1. The materials of Perforated sheet: stainless steel plate,iron plate,copper plate,aluminum plate,electro galvanized steel plate, hot-dipped galvanized steel plate etc.
2. The dimension of Perforated sheet size can be according to the customers’ requirement
3. Hole shapes: round,squared,oblong,elliptical,rectangular,star-shaped.diamond and fancy.
4. The surface treatment of Perforated sheet: galvanized coated,powder coating,polishing
5. Packing: as to according to the customers’ requirement
The features of Perforated sheet
winding-resisting,Aging-resisting,corrosion-resisting,the top of meshes is smooth,it is strong and durable,light weight,skid prevention and artistic.
The applications of Perforated sheet
1. The applications: Widely applies in the chemical machinery, the drugs manufacture equipment, food drink machinery, the cigarette machinery, the harvester, dry cleans machine etc
2. Used: widely used in the core of filter, medicine, filtering, breeding, battery, mechanical protecting, making the crafts, the meshes for the high-grade sound box, decoration, the seating for children, baskets, etc.
If you are interested in our product, pls feel free to contact us. TEL: 0086-10-68283337 Email: service.wzjd@hotmail.com

Reference specifications of Perforated sheet

Plate Material	Thickness of Metal (mm)	Hole Dia. (mm)	Pitch(mm)	Sheet Width (m)	Sheet Length (m)	Porosity(%)	Weight(kg/m2)
Rolling plate	0.2	6	2	1	20	44	0.88
	0.35	5	4	1	20	24	2
	0.45	6	3	1	20	35	2.5
	0.8	3	3	1	20	19.6	3
Flat plate	0.5	1	1	1	2	19.6	3.14
	0.55	1.1	2.2	1	2	22.67	3.411
	0.55	1.5	2.8	1	2	26.03	3.268
	0.8	1.5	1.5	1	2	19.6	5
	0.8	2.0	3.4	1	2	30.78	4.465
	1.5	2	2	1	2	19.6	9.4
	1.5	5.0	8.0	1	2	35.39	7.843
	3	5	16	1	2	19.6	18.8
Stainless steel plate	0.5	1	1	1	2	19.6	3.14
	0.8	1.5	1.5	1	2	19.6	5
	1	2	2	1	2	19.6	6.28
	2	5	16	1	2	19.6	6.28
Aluminum plate	0.5	1	1	1	2	19.6	1.08
	0.8	3	3	1	2	19.6	1.72
	1.6	2	2	1	2	19.6	3.24
	3	4	16	1	2	19.6	4.23
