Wire screen mesh
Wire screen mesh
- Category:Stainless Steel Wire Mesh
- Material:stainless steel wire 304, 316 and so on
- Properties:Woven Wire Mesh
- Application:utilized as filter fittings for chemical industry
tags:
Wire screen mesh,Wire screen,Wire mesh,
or
We highly appreciate your feedback. TEL: 0086-10-68220585 E-mail: sales@kingdamesh.com
- Mesh Description
- Mesh Specification
- Relevant Picture
- Recommend Products
Wire screen mesh
1. Wire screen mesh materials: Stainless Steel Wire: AISI 304, 304L, 316, 316L, 310, 314, 410, and 430.
2. Weave types of the wire screen mesh:
2.1 Wire screen mesh plain weave: Each weft wire passes over one and under warp wire, and each warp wire passes over one and under weft wire. Every weft wire has same diameter.
of filters, colanders for aliments, chemicals products, shielding, mosquito nets, etc.
2.2 Wire screen mesh twilled weave: In the Twilled Woven Wire Mesh, the wires of the weft and the warp intercross two above and two below, inverting the intersections of the warp wire at an established distance and obtaining a rigid, stable and robust type of wire mesh fabric.
2.3 Wire screen mesh Dutch weave: In Dutch Twilled Weave Wire Mesh, the wire of the weft and the warp intercross two above with a larger weft wire than the warp. To reduce the mesh opening, this kind of wire mesh allows a greater difference between the diameter and the number of weft and warp wire.
2.4 Wire screen mesh Reverse Dutch weave: the basic filter material for pharmacy, food, medicine, chemical and other industries.
3. Application of the wire screen mesh:
Wire screen mesh is utilized as filter fittings for chemical industry, medicine, petroleum, telecom-communication, scientific research units and so on.
