1/4 inch Welded Wire Mesh,1/4 inch Welded Wire Mesh manufacturer.-Wuzhou Kingda Wire Cloth Co. Ltd

Category:Welded Wire Mesh
Material:Low carbon wire,Galvanized wire,PVC wire.
Properties:corrosion resistance, aging resistance,etc.
Application:industry,agriculture,construction,transportation,mining industry,etc.

We highly appreciate your feedback. TEL:0086-10-68283337 TEL: 0086-10-68283337 E-mail: sales@kingdamesh.com

The specification of the 1/4 inch Welded Wire Mesh
1. The material of the 1/4 inch Welded Wire Mesh:Low carbon wire,Galvanized wire,PVC wire.
2. The wire diameter of the 1/4 inch Welded Wire Mesh:BWG:22,23,24.
3. The width of the 1/4 inch Welded Wire Mesh:2”-6”.
4. The package of the 1/4 inch Welded Wire Mesh:Water-proof Paper/Shirked Plastic Bag Or according to your requirements.
5. The delivery time of the 1/4 inch Welded Wire Mesh: About 15days after received your deposit.
The features of the 1/4 inch Welded Wire Mesh
The 1/4 inch Welded Wire Mesh is corrosion resistance, aging resistance, sunshine resistance and weather resistance.
The application of the 1/4 inch Welded Wire Mesh
The 1/4 inch Welded Wire Mesh can be used as poultry case, egg basket, passageway rail, waterspout, lobby guardrail, rodent-resistant net, mechanical shield, livestock and plants guardrail and fences, etc. in industry, agriculture, construction, transportation and mining industry, etc.

If you are interested in our products,please feel free to contact us.TEL:0086-10-68283337.
Email: service.wzjd@hotmail.com

Specification List of Welded Wire Mesh
Opening		Wire Diameter
In inch	In metric unit(mm)	Wire Diameter
1/4" x 1/4"	6.4mm x 6.4mm	22,23,24
3/8" x 3/8"	10.6mm x 10.6mm	19,20,21,22
1/2" x 1/2"	12.7mm x 12.7mm	16,17,18,19,20,21,22,23
5/8" x 5/8"	16mm x 16mm	18,19,20,21,
3/4" x 3/4"	19.1mm x 19.1mm	16,17,18,19,20,21
1" x 1/2"	25.4mm x 12.7mm	16,17,18,19,20,21
1-1/2" x 1-1/2"	38mm x 38mm	14,15,16,17,18,19
1" x 2"	25.4mm x 50.8mm	14,15,16
2" x 2"	50.8mm x 50.8mm	12,13,14,15,16
Technical Note: 1,Standard roll length: 30m;width: 0.5m to 1.8m 2,Special sizes available at request 3,Packing: in waterproof paper in rolls. Custom packing available at request.

Galvanized welded Mesh fenceing
Opening		Wire Diameter
In inch	In metric unit(mm)	Wire Diameter
2" x 3"	50mm x 75mm	2.0mm,2.5mm,1.65mm
3" x 3"	75mm x 75mm	2.67mm,2.41mm,2.11mm,1.83mm,1.65mm
2" x 4"	50mm x 100mm	2.11mm,2.5mm
4" x 4"	100mm x 100mm	2.0mm,2.5mm
Technical Note: 1,Standard roll length: 30m;width: 0.5m to 1.8m 2,Special sizes available at request 3,Packing: in waterproof paper in rolls. Custom packing available at request.
PVC Coated Welded Mesh
Opening		Wire Diameter
In inch	In metric unit(mm)	Wire Diameter
1/2" x 1/2"	12.7mm x 12.7mm	16,17,18,19,20,21
3/4" x 3/4"	19mm x 19mm	16,17,18,19,20,21
1" x 1"	25.4mm x 25.4mm	15,16,17,18,19,20
